#Adafruit motor shield serial#
After each of these changes, a serial value is sent back to the serial monitor. The example creates a serial connection and then ramps the motor up and then back down. I am certain that I have gone SDA to SDA and SCL to SCL pins to the Arduino Uno as it is documented yet it never seems to make the i2c connection. Just in case my connections to my motor were bad to the M1 output, I also tested with a volt meter to verify that no voltage was coming off the M1 outputs. I tried powering the Arduino then the motor shield etc. I tried powering the motor shield for a minute, then powering the Arduino to see if the order made a difference in the two making the i2C connection. I tried cycling the power on both Arduino and motor shield to see if it was a handshake or startup issue.
#Adafruit motor shield driver#
I tried them backwards, soldered pins to the A4 and A5 on the motor driver (in case I was misreading the documentation) and tested them to connect to the Arduino. I put the leads from the SDA and SCL pins on the motor shield to the A4 and A5 pins, the SDA and SCL pins in both permutations, as well as the pins labeled SDA and SCL on my Arduino Uno. To simplify my test, I have only one motor attached to the output labeled M1 on the motor driver and no other sensors or pins used by the Arduino except the two for SDA and SCL.Īs part of my numerous tests, I tried all of the permutations I can think of. I then downloaded the example DCMotorsTest (File->Examples->Adafruit_MotorShield->DCMotorTest in the Arduino IDE) into the Arduino Uno. For power to the Arduino, I used the USB cable connected to my laptop. I got a steady and what I consider bright green light on the LED on the motor driver. I removed the jumper for the Motor Power and applied the power leads from the separate supply as documented.
I soldered two pins onto the SDA and SCL pins on the motor shield. Because of room and where this is going on my final project, I do not want to use this as a shield on the Arduino Uno. I also carefully read the section on "What pins are/are not used on the motor shield?" I read that the SDA and SCL i2C pins are all that is needed to control the motors.
#Adafruit motor shield how to#
or-arduino) which very well documented how to install the library and what example software to get working. I verified that I am wiring the motor correctly based on your excellent documentation and clearly marked PCB.
#Adafruit motor shield code#
I have a bright green LED from the motor driver while on a separate power supply, but for some reason the example code that comes with the library DCMotorsTest does not provide power to the motor one leads. I am unable to get it to work and am not sure what I am doing wrong. How to send g-code to Netduino: please use some software which can send HTTP POST requests.Yesterday, I had two of your motor shields arrive in the mail which I want to use to drive 4 small motors using a dc supply that puts out 7.5 - 8 volts and is rated for 2 amps of output. Next step: just deploy the app to Netduino and everything is ready to print pictures. Please use instructions form Step 2 from this article: Netduino WiFi Lock Then we need to setup a Netduino wifi connection. Or you can craft it using ordinary Nema17 stepper motors: video You can take stepper motors from old CD/DVD drives: video 2. Thank you David Suarez for the g-code parser.įirst things first we need to assemble a plotter.
For this purpose, I took g-code parser from this project and made few modifications to make it work.
Of course I took some parts from Tigra Astronomy but in general, it was developed from scratch.Īnother thing we need is a g-code parser which converts graphical g-code instructions to steps for stepper motors. But I couldn't make it work and I decided to develop my own. You may say that this library works with an Adafruit motor shield. If you use Netduino you probably know that, unfortunately, there is no library for Adafruit motor shield. Yes, it is yet another one CNC plotter project, but this time it was made using Netduino 3 and Adafruit motor shield.
